CNA configuration rules
Table 4 HP CNA requirements
DescriptionItem
2
Number of CNAs per server
(maximum)
• SFP+ optical
• Copper
Cable types
For current firmware and driver support, see the SPOCK website at http://www.hp.com/storage/
spock. You must sign up for an HP Passport to enable access.
FCoE CN switch configuration rules
Table 5 DC SAN Director Switch 10/24 FCoE Blade and 2408 FCoE Converged Network Switch fabric
rules
DescriptionRule number
A 2408 FCoE Converged Network Switch or DC SAN Director Switch 10/24 Blade can be
a standalone switch or an edge switch in a Fibre Channel fabric. To attach the switch to an
existing Fibre Channel fabric as an edge switch, at least one Fibre Channel port on the FCoE
CN switch must be connected to a Fibre Channel switch in the fabric (E_Port). There cannot
be any other FCoE or 10-GbE CEE switches in the path to the Fibre Channel switch.
Similarly, a DC or DC04 SAN Director with a 10/24 FCoE Blade installed can be a
standalone switch, an edge switch, or a core switch in a Fibre Channel fabric. If it is an edge
switch or core switch, other switches in the fabric can be attached to any available FC port
(E_Port) on other FC blades in the director.
For FCoE E_Port connectivity, see the appropriate Fabric OS release notes for the minimum
and recommended Fibre Channel switch firmware versions and the supported Fibre Channel
switch models. HP recommends Brocade FOS 6.3.0b or later.
1
Server CNAs must be directly connected to the CEE ports on a 2408 FCoE Converged Network
Switch or DC SAN Director Switch 10/24 FCoE Blade.
2
Fibre Channel storage can be directly connected to the 2408 FCoE Converged Network
Switch (one of the eight FC F_Ports) or to any Fibre Channel switch that is part of the same
fabric as the 2408 FCoE Converged Network Switch.
With the DC SAN Director Switch 10/24 FCoE Blade, storage can be connected to any of
the other FC blades in the same director or to any Fibre Channel switch that is part of the
same fabric as the DC SAN Director that contains the DC SAN Director Switch 10/24 FCoE
Blade.
3
Supports a maximum of seven switch hops (eight switches) between a CNA and storage.4
Supports the following CEE media types:
• HP B-series hot pluggable, 10-GbE SFP+ Short Reach (SR) and Long Reach (LR) optical
transceivers
• HP B-series SFP+ 1 m, 3 m, or 5 m copper Twinax active cables (2408 FCoE Converged
Network Switch only)
5
Up to 4,000 VLANs, but only one FCoE VLAN is currently supported6
Only FPMA is currently supported.7
HP StorageWorks Fibre Channel Over Ethernet Application Note 17
