Configuration rules
This section describes configuration rules for the HP FCoE solution. The rules are defined for the CNAs
and each of the FCoE CN switch series.
Figure 8 shows a converged SAN fabric with servers using CNAs only.
26647b
Server
with CNA
IP network
Server
with CNA
X-series
FCoE switch
FC attached
HP storage
Fabric A
X-series
FC switch
Server
with CNA
Server
with CNA
X-series
FCoE switch
FC attached
HP storage
10-GbE
Fabric B
X-series
FC switch
X-series
FCoE switch
X-series
FCoE switch
10-GbE/FCoE A/FCoE B connection
Fabric A Fibre Channel connection
Fabric B Fibre Channel connection
10-GbE connection
Figure 8 Converged SAN fabric configuration
.
12
