HP C-series Nexus 5010/20 Converged Network Switch quick setup
This procedure is intended for users who are familiar with Cisco MDS FC switches and have experience
merging C-series MDS FC switches into an existing MDS FC fabric. Use this procedure to enable
servers with CNAs attached to the HP C-series Nexus 5010/20 Converged Network Switch to access
devices on the attached C-series FC fabric.
IMPORTANT:
If you are not familiar with Cisco FC switches or you do not have experience merging C-series FC
switches into an existing FC fabric, use the detailed instructions found in the switch user guide to set
up your switch.
HP recommends that you use the VFC port assignments listed in Table 7.
Table 7 Recommended VFC port assignments
VFC port assignments
nl
(recommended)
Number of FCoE ports
nl
(maximum)SlotModel
VFC ports 1 through 20201 (Standard)HP C-series
Nexus 5010
Converged
Network
Switch
VFC ports 41 through 466
2 (Optional expansion
nl
module slot
1
)
VFC ports 1 through 40401 (Standard)
HP C-series
Nexus 5020
Converged
Network
Switch
VFC ports 41 through 466
2 (Optional expansion
nl
module slot
1
)
VFC ports 47 through 526
3 (Optional expansion
nl
module slot
1
)
1
Optional expansion module slots can contain either 10-GbE ports or FC ports.
In the following examples, FCoE is enabled on a C-series Nexus 5010 Converged Network Switch,
VLAN 200 is created, and the Ethernet ports are bound to a virtual SAN (VSAN 2) from an 8-port
FC expansion module. The commands are the same for the HP C-series Nexus 5020 Switch.
HP StorageWorks Fibre Channel Over Ethernet Application Note 25
