Figure 9 shows a converged SAN fabric with servers using CNAs connected to a B-series CN switch
and a DC SAN Director Switch 10/24 FCoE Blade.
26648b
Server
with CNA
IP network
Server
with CNA
B-series
CN switch
FC attached
HP storage
Fabric A
B-series
FCoE
blade
Server
with CNA
Server
with CNA
FC attached
HP storage
10-GbE
Fabric B
B-series
CN switch
B-series
FCoE
blade
10-GbE/FCoE A/FCoE B connection
Fabric A Fibre Channel connection
Fabric B Fibre Channel connection
10-GbE connection
Figure 9 Converged SAN fabric with an FCoE blade
.
HP StorageWorks Fibre Channel Over Ethernet Application Note 13
