HP ProLiant DL320e Gen8 - Redundant Power Supply Cabling

Cabling 60
Redundant power supply cabling
Item Description
1
24-pin power supply cable
2
26-pin RPS cable
3
4-pin power supply cable
CAUTION: The default and redundant power supplies in the server must have the same output
power capacity. Verify that all power supplies have the same part number and label color. The
system becomes unstable and might shut down when it detects mismatched power supplies.
