HP ProLiant DL380 Generation9

QuickSpecs
HPE ProLiant DL380 Generation9 (Gen9)
Configuration Information - Factory Integrated Models
Page 27
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, Hewlett Packard Enterprise recommends the use of an HPE approved
configurator. Contact your local sales representative for
information on configurable product offerings and requirements.
1. Factory Integrated Models must start with a CTO Server.
2. FIO indicates that this option is only available as a factory installable option.
3. All Factory Integrated Models will be populated with sufficient hard drive blanks based on the number of initial hard drives ordered
with the server.
4. Some options may not be integrated at the factory. Contact your local sales representative for additional information.
Step 1: Base Configuration (choose one of the following configurable models)
CTO Server
Models
HP ProLiant DL380
Gen9 8SFF
Configure-to-order
Server
HP ProLiant
DL380 Gen9
NVMe 6 Solid State
Drive Express Bay
Configure-to-order
Server
HP ProLiant
DL380 Gen9
24SFF Configure-
to-order Server
HP ProLiant
DL380 Gen9 4LFF
Configure-to-order
Server
HP ProLiant DL380
Gen9 12LFF
Configure-to-order
Server
SKU Number
719064-B21
810393-B21
767032-B21
767033-B21
719061-B21
Processor
2 (optional) x HPE Smart Socket Guide
DIMM Slots
24 DIMM slots for RDIMM, LRDIMM DDR4 Memory
Storage
Controller
HPE Dynamic Smart Array B140i, plus optional HPE Flexible Smart Array or Smart HBA controller
PCIe
3 PCIe slots (+3 PCI slots available with upgrade option, second processor required)
Drive Cage
8SFF Hot Plug
(+8SFF and Universal
Media Bay Optional)
8SFF +6NVMe Hot
Plug (+8SFF or
Universal Media
Bay Optional)
24SFF Hot Plug
4LFF Hot Plug
12LFF Hot Plug
Network
Controller
HPE Embedded 1Gb
Ethernet 4-
port 331i
Adapter, plus
optional HPE Flexible
LOM or stand up
card
HPE Embedded
1Gb Ethernet 4-
port 331i Adapter
HPE Embedded 1Gb Ethernet 4-port 331i Adapter, plus optional
HPE Flexible LOM or stand up card
Fans
4 hot plug fans,
redundant
6 hot plug high performance fans,
redundant
4 hot plug fans,
redundant
6 hot plug high
performance fans,
redundant
Management
iLO Management (standard), Intelligent Provisioning (standard)
USB
1 front, 2 internal, 2
rear
1 front, 1 internal, 2
rear
1 front, 2 internal, 2
rear
No front USB support
Ears
HPE Quick Release Ears
NOTE: With the NVMe CTO Server (810393-B21) there are limitations on GPU support.
NOTE: The NVMe CTO Server (810393-B21) ships with the standard x8 Risers supporting 2xNVMe drives.
Step 2: Choose Required Options (only one of the following from each list unless otherwise noted)
HPE Processors
Entry Processors – E5-2600v4 series Processors
HP DL380 Gen9 Intel® Xeon® E5-2650Lv4 (1.7GHz/14-core/35MB/65W) FIO
Processor Kit
817941-L21
HP DL380 Gen9 Intel® Xeon® E5-2630Lv3 (1.8GHz/10-core/25MB/55W) FIO
Processor Kit
817931-L21
