Cabling 63
Optical drive cabling
Optical drive cabling in a nonredundant power configuration
Item Description
1
Upper optical drive power cable
2
Lower optical drive SATA cable
3
Upper optical drive SATA cable
4
Lower optical drive power cable
Optical drive cabling in a redundant power configuration
