HP ProLiant ML310e Specification

Power Specifications To review typical system power requirements, use the HP Power Advisor which is available via download
at URL: www.hp.com/go/proliant-energy-efficient or www.hp.com/go/hppoweradvisor .
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_div/14209_div.html
Power Supplies The ML310e Gen8 v2 supports two power supplies, a 350W Multi-Output Power Supply and a 460W
Common Slot Gold Power Supply. The 350W Multi-Output Power Supply is a non-redundant power supply
with an efficiency rating of 85%.
HP's Common Slot (CS) power supplies allow for commonality of power supplies across a wide range of
ProLiant and Integrity servers, as well as HP Storage solutions, and are designed to provide the highest
power supply efficiency without degrading system performance. HP CS power supplies are tested by the
Electric Power Research Institute (EPRI) and certified through the ECOS 80 Plus power supply program.
The 460W HP CS power supply option provides an efficiency rating of up to 92%. All HP Common Slot
power sources are UL, CE Mark Compliant, hot-plug and support redundant configurations.
NOTE: Mixing of power supplies in the same server is not supported. All power supplies must be of the
same output and efficiency rating. If non-matched power supplies are inserted you will get errors and
operation will fail.
It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for
your needs. HP Power Advisor can be accessed at: www.hp.com/go/hppoweradvisor .
NOTE: The 80 PLUS program is a unique forum that unites electric utilities, the computer industry, and
consumers in an effort to bring energy efficient technology solutions to the marketplace. 80 Plus
independently tests power supply efficiency and publicly posts the results on 80Plus.org.
Redundant Power: Optional (1 + 1 redundant) power supplies can be purchased through power supply
option kits (see Power Supplies for part numbers).
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_div/14209_div.html
System Fans One (1) Non-redundant system fan ships standard
One (1) Non-redundant PCIe fan ships standard
QuickSpecs
HP ProLiant ML310e Generation 8 (Gen8) v2
Standard Features
DA - 14564 Worldwide — Version 11 — December 13, 2013 Page 6

HP ProLiant ML310e Specifications

General

Bus type	DMI
Stepping	C0
FSB Parity	No
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E3-1220V3
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200 v3
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Motherboard chipset	Intel® C222
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Thermal solution specification	PCG 2013D
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	3.5 \
HDD speed	7200 RPM
RAID levels	0, 1, 10
HDD interface	Serial ATA III
Optical drive type	DVD-RW
Total storage capacity	1000 GB
Maximum storage capacity	16 TB
Supported storage drive interfaces	SAS, Serial ATA
Internal memory	4 GB
Memory clock speed	1333 MHz
Memory layout (slots x size)	1 x 4 GB
Maximum graphics card memory	16 MB
On-board graphics card model	Not available
Graphics card	G200
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
PCI Express slots version	3.0
Operating system installed	-
Compatible operating systems	Windows Server\\r Ubuntu\\r Red Hat Enterprise Linux\\r SUSE Linux Enterprise Server\\r VMware
Noise level	26 dB
Chassis type	Tower (4U)
Power supply	350 W
Power supply input frequency	47/63 Hz
Certification	FCC; CISPR 22; EN55022; EN55024; FCC CFR 47; ICES-003; CNS13438; GB9254; K22; K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC 60950-1
Processor ARK ID	75052
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	475.2 mm
Width	175 mm
Height	368.2 mm
Weight	18960 g
