Rear components
Figure 1-4 Rear components
Table 1-3 Rear components
Component Component
1 Access panel 7 RJ-45 Gigabit Ethernet port
2 Access panel latches 8 (2) USB 3.0 ports
3 Security lock slot 9 DisplayPort connector
4 Power connector 10 Stereo audio line out
5 (2) PS/2 mouse and keyboard connectors 11 Access panel security screw
6 (2) USB 2.0 ports 12 Serial port (optional)
Rear components
5
