4. If your second display does not have a DisplayPort connector, connect a DisplayPort video
adapter to the DisplayPort connector of the computer. Then connect a cable (VGA, DVI. or HDMI,
depending on your application) between the adapter and a second display.
NOTE: When a DisplayPort adaptor is used, the rear port cover cannot be installed unless a
DisplayPort extender cable is used in conjunction with the adaptor.
Figure 2-24 Connecting a second display Using a DisplayPort adapter
5. Replace the rear port cover on the computer.
6. Turn on power to the computer and the second display.
NOTE: Use the graphics card software or the Windows Display Settings to configure the second
display as a mirrored image of the primary display or an extension of the primary display.
26 Chapter 2 Hardware repair and upgrade
