9. Slide the drive adapter holding the 2.5-inch drive or drives out of the drive cage.
Figure 2-40 Removing the 2.5-inch drive adapter from the drive cage
10. Remove the four mounting screws from the 2.5-inch hard disc drive adapter. Be sure to keep the
screws together with the blue rubber grommets to use to install a replacement drive.
NOTE: The primary drive is the lower position in the drive cage. If only one drive is to be
installed, it must occupy this position.
Figure 2-41 Removing the mounting screws from the 2.5-inch drive adapter
11. Remove the 2.5-inch hard disc drive(s) from the 2.5-inch drive adapter.
For instructions on installing a hard disc drive, see
Installing a hard disc drive on page 40.
Replacing drives
39
