1–10 Maintenance and Service Guide
Product Description
1. 3 D es i g n O ve r v i ew
This section presents a design overview of key parts and features
of the QuickDock. Refer to Chapter 3, “Illustrated Parts Catalog,
to identify replacement parts.
The QuickDock provides the following device connections:
Expansion cable
S/PDIF (Sony/Philips Digital Interface) audio connector
Audio-out (headphone) jack
Composite out
RJ-11 (modem) connection (from telephone to QuickDock)
RJ-11 (modem) connection (from QuickDock to computer)
RJ-45 (network) port
USB 2.0 connectors (3)
S-Video-out
Serial port
Ä
CAUTION: To properly ventilate the QuickDock, allow at least a
7.6-cm (3-inch) clearance on the left and right sides of the unit.
The computer uses an electric fan for ventilation. The fan is
controlled by a temperature sensor and is designed to turn on
automatically when high temperature conditions exist. These
conditions are affected by high external temperatures, system
power consumption, power management/battery conservation
configurations, battery fast charging, and software.
