9
Dock Lights and Buttons
#
Name Description
1Spare
battery
charging
light
Shows the power/battery charging status. If this
light is:
! On - the spare battery in the dock is fully charged
! Blinking - the spare battery in the dock is charging
! Off - there is no spare battery in the dock, or the
battery has been inserted incorrectly
2
Save/Print
button
Activates the connection to the computer or the
printer, depending on which of those devices is
attached to the dock. If the light above this button
is:
! On - the dock is connected to the computer or
printer
! Blinking - there is an active connection between
the camera and the computer or printer
3
TV button
Activates the television (TV) connection, which
starts the slideshow of images. If the light above
this button is:
! On - the dock is connected to the TV
! Blinking - an audio/video signal is being sent to
the TV
1
23 4
