Components, parts and materials containing
radioactive substances
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Size (if
applicable)
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove the middle bezel and left panel
2. Disconnect the battery connector, and press on/off button to discharge the rest electricity.
3. Loosen the screws fixing the battery door, remove the battery door, and pull out the battery.
4. Loosen the screws fixing the right panel ASSY, and remove the right panel ASSY.
5. Disconnect the LCD cable and PCBA.
6. Loosen the screws fixing the top cover, and remove the top cover.
7. Disconnect the cables connecting to Slot box, AVR, rear FAN, COM PCBA, and rear panel ASSY, and disassemble
the cable clips sticking on the mainframe, and loosen the screws fixing the main PCBA, then remove the main PCBA .
8. Cut off the cable tie, disconnect the cable connecting to COM PCBA, loosen the nuts fixing the AVR, and then remove
the AVR.
9. Lossen the screws fixing rear panel ASSY and then remove the rear panel ASSY.
10. Remove the RPO connector, loosen the screws fixing SLOT box, COM PCBA and rear FAN, loosen the nut fixing
ground cable and then remove the Slot Box, COM PCBA and rear FAN, outlet.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
