Chapter 1
Wheel Kit Installation Guide
Wheel Kit Installation
4
Wheel Kit Installation
NOTE Wheel kits are available in both dark and light colors.
Compare the packing list with the contents of the wheel kit before beginning the installation.
Tools Required for Installation
The following list provides the installer with the recommended tools to perform the wheel kit installation.
• Diagonal side cutters
• Safety glasses
• Torx driver with T-15 bit
• Phillips head screwdriver
WARNING Wear protective glasses while cutting the plastic bands around the shipping
container. These bands are under tension. When cut, they can spring back and cause
serious eye injury.
Table 1-1 Wheel Kit Packing List
Part Number
(Light Color)
Part Number
(Dark Color)
Description Quantity
A6753-04013 A9903-04001 Wheel Kit consisting of the
following components:
1
A6753-04002 A9903-04006 Side Cover 1
A6753-04003 A9903-04007 Side Cover 1
A6753-04004 A9903-04008 Top Cover 1
A6753-00007 A9903-00001 Caster Cover 2
A6753-04001 A9903-04002 Right Front Caster Assembly 1
A6753-04005 A9903-04003 Right Rear Caster Assembly 1
A6753-04006 A9903-04004 Left Front Caster Assembly 1
A6753-04007 A9903-04005 Left Rear Caster Assembly 1
0515-2478 0515-2478 M4 x 0.7 8mm T15 Steel Zinc
Machine Screw (Used to attach
each caster to the chassis)
4
A6093-44013 A6093-44013 Plywood Unloading Ramp 1
Not Applicable Not Applicable Phillips Head Wood Screw (Used
to attach the ramp to the pallet)
2
