Chapter 1
Wheel Kit Installation Guide
Wheel Kit Installation
5
1. Cut and remove the polystrap bands securing the HP Server to the pallet.
2. Lift the carton top from the cardboard tray resting on the pallet.
3. Remove the Wheel Kit carton and the top cushions from the pallet.
Figure 1-1 Component Locations
4. Unfold bottom cardboard tray.
MWK001
3/10/03
Top Cushions
Cardboard Tray
Bezel
Kit
To Next Page
