EL-MF877-00 Page 11
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Align the visa cover to the bracket
and press the clip to lock on to the
bracket see photo1
Confirm the visa cover locked well,
see photo 2 and 3
Disassembly process (Installing back cover bracket)
Align the rear cover to the unit by
the two latch see photo 1
Push the rear cover to end , see picture 2
Double check the rear cover locked
well, see photo 4
Disassembly process (Assemble MCR, webcam, BIO reader (If necessary)
To Next Page
