HP S430c - DC Power Jack Connector (CN701) Repair

21
3) Lift the DP connector from the circuit board.
4) Place the new component on the circuit board. Be sure that it matches the circuit board footprint.
5) Solder the new component.
DC Power Jack connector CN701
Repair the DC Power Jack connector:
1) Use a soldering iron and a de-soldering pump to remove as much solder as possible from the pin.
2) Lift the DC Power Jack connector from the circuit board.
3) Place the new component on the circuit board. Be sure that it matches the circuit board footprint.
4) Solder the new component.
