HP S430c User Manual

3
2 Monitor features
This chapter provides an overview of the monitor’s features.
Features
The monitor includes the following features:
● 110.24 cm (43.4 in) curved 1800 mm radius with 3840 × 1200 resolution, ultrawide backlit display, plus full-
screen support for lower resolutions
● Antiglare panel with an LED backlight
● Wide viewing angle to allow viewing from a sitting or standing position, or when moving from side to side
● Integrated HP Device Bridge technology that allows you to use a single keyboard and mouse across two connected
computers to control software and transfer files and data from one computer to the other
● Integrated pop-up infrared (IR) and RGB camera with noise cancelling microphones for conferencing and Microsoft
Windows® Hello support
● Tilt adjustment capability
● Height adjustment capability
● DisplayPort™ (DP) video input
● High-Definition Multimedia Interface (HDMI) video input (cable provided)
● USB Type-C port with power delivery up to 65 W and DisplayPort Alternate Mode (DP Alt Mode)
● Dynamic power delivery up to 110 W distributed between USB Type-C port #1 and USB Type- C port #2
● USB 3.0 hub with two USB Type-C ports that connect to a computer (upstream); and four USB ports that connect to
USB devices (downstream)
● USB cable provided to connect the monitor's USB hub to the USB port on the computer
● Audio-out (headphone) jack
● Plug and Play capability, if supported by your operating system
● Security cable slot provision on rear of monitor for optional security cable
● On-screen display (OSD) adjustments in several languages for easy setup and screen optimization
● High-bandwidth Digital Content Protection (HDCP) copy protection on all digital inputs
● VESA® mounting bracket for attaching the monitor to a wall-mount device or swing arm
● Low blue light mode settings to create a more relaxing and less stimulating image
● Energy saver feature to meet requirements for reduced power consumption
NOTE: For safety and regulatory information, see the Product Notices provided in your documentation kit. To access the
latest user guide, go to http://www.hp.com/support and follow the instructions to find your product. Then select User Guides.

HP S430c Specifications

General

HD type	WUXGA
Panel type	VA
Pixel pitch	0.274 x 0.274 mm
Pixel density	92 ppi
Display diagonal	43.4 \
Display resolution	3840 x 1200 pixels
Display technology	LED
Native aspect ratio	32:10
Maximum refresh rate	60 Hz
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	3000:1
Display number of colors	-
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 1200
HDMI	Yes
USB hub version	3.2 Gen 2 (3.1 Gen 2)
DisplayPort version	1.2
USB Type-C downstream ports quantity	2
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
Power consumption (standby)	0.5 W
Power consumption (typical)	80 W
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Certification	BSMI; CB; CCC; CE; CEL; cTUVus; EAC; EPA; FCC; ICES; ISO 9241-307; KCC; PSB; TCO Certified; UV-S; UL; VCCI; WEEE; ISC
Product color	Black, Silver
Market positioning	Gaming
Cables included	AC, HDMI, USB Type-C to USB Type-A, USB Type-C to USB Type-C
HP segment	Business
Package type	Box
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	256 mm
Height (with stand)	491 mm
Depth (without stand)	140.8 mm
Width (without stand)	1057 mm
Height (without stand)	361.9 mm
Weight (without stand)	14300 g
