HP S430c User Manual

26
“Check Video Cable” is
Monitor video cable is disconnected.
Connect the appropriate video signal cable between the
computer and monitor. Be sure that the computer power is off
while connecting the video cable.
“Input Signal Out of Range”
is displayed on screen.
Video resolution and/or refresh rate
are set higher than the monitor
supports.
Change the settings to a supported setting (see Preset display
resolutions 63.5 cm (25 in) model on page 30 or Preset
display resolutions 68.6 cm (27 in) model on page 31).
The monitor does not enter
into a low-power sleep state.
The monitor's power saving control is
disabled.
Open the OSD menu and select Power, select Auto-Sleep
Mode, and then set auto-sleep to On.
“OSD Lockout” is displayed.
The monitor's OSD Lockout
function is enabled.
Press and hold the left button on the front of the monitor for
10 seconds to disable the OSD Lockout function.
“Power Button Lockout”
is displayed.
The monitor's Power Button Lockout
feature is enabled.
Press and hold the Power button for 10 seconds to unlock the
power button function.
Image on monitor displays in
low contrast and low
saturation. There are no solid
blacks. Only dark grays
appear.
The Video Level setting in the OSD
menu is not set appropriately for your
monitor configuration.
In the OSD menu, select Image, and then select Video Level.
Change the setting to Limited Range (64-940) .
Image on monitor displays
blacks and whites in low
detail and high contrast.
Colors appear over
saturated, and incorr ct
colors are
apparent.
The Video Level setting in the OSD
menu is not set appropriately for your
monitor configuration.
In the OSD menu, select Image, and then select Video Level.
Change the setting to Full Range (0-1023).
No image appears on the
monitor.
Your graphics card is not compatible
with DisplayPort 1.4 mode.
If your monitor is connected to the computer using the
DisplayPort connector, change the DisplayPort Mode from the
default DisplayPort 1.4 mode to an older version such as
DisplayPort 1.2 or DisplayPort 1.1.
Monitor wakes slowly from
sleep mode or does not wake at
all.
The DP Hot-Plug Detection setting in
the OSD menu is not set
appropriately for your monitor
configuration.
In the OSD menu, select Input, and then select DP Hot-Plug
Detection. Change the setting from Low power (default) to
Always Active.

HP S430c Specifications

General

HD type	WUXGA
Panel type	VA
Pixel pitch	0.274 x 0.274 mm
Pixel density	92 ppi
Display diagonal	43.4 \
Display resolution	3840 x 1200 pixels
Display technology	LED
Native aspect ratio	32:10
Maximum refresh rate	60 Hz
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	3000:1
Display number of colors	-
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 1200
HDMI	Yes
USB hub version	3.2 Gen 2 (3.1 Gen 2)
DisplayPort version	1.2
USB Type-C downstream ports quantity	2
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
Power consumption (standby)	0.5 W
Power consumption (typical)	80 W
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Certification	BSMI; CB; CCC; CE; CEL; cTUVus; EAC; EPA; FCC; ICES; ISO 9241-307; KCC; PSB; TCO Certified; UV-S; UL; VCCI; WEEE; ISC
Product color	Black, Silver
Market positioning	Gaming
Cables included	AC, HDMI, USB Type-C to USB Type-A, USB Type-C to USB Type-C
HP segment	Business
Package type	Box
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	256 mm
Height (with stand)	491 mm
Depth (without stand)	140.8 mm
Width (without stand)	1057 mm
Height (without stand)	361.9 mm
Weight (without stand)	14300 g
