Miscellaneous parts
Component Spare part number
10-W, 5-V, 2-A, USB, AC adapter
For use only in Europe and South Korea 744423-009
For use only in India 744423-005
For use only in the People's Republic of China 744423-006
HP Slate7 VoiceTab equipped with a 7-in., IPS, LCD, TouchScreen display panel, a Marvel
PXA1088 1.20-GHz quad core processor, 1.0-GB LP-DDR2 system memory, and a 16.0-
GB eMMC solid state drive
751317-001
Screw Kit 751313-001
USB extension cable 751316-001
and 751657-001
Sequential part number listing
Spare part number Description
744423-005 10-W, 5-V, 2-A, USB, AC adapter for use only in India (includes duck head adapter)
744423-006 10-W, 5-V, 2-A, USB, AC adapter for use only in the People's Republic of China (includes
duck head adapter)
744423-009 10-W, 5-V, 2-A, USB, AC adapter for use only in Europe and South Korea (includes
duck head adapter)
751300-001 System board equipped with a Marvel PXA1088 1.20-GHz quad core processor, 1.0-GB LP-DDR2
system memory, and a 16.0-GB eMMC solid state drive (includes left and right speakers and
vibrator module)
751301-001 7-in., IPS, LCD, TouchScreen display panel assembly
751302-001 Back cover
751304-001 Middle frame
751305-001 Power/volume button board (includes cable and double-sided adhesive)
751307-001 Speaker/Vibrator Module Kit (includes left and right speakers, cables, and grommets and vibrator
module and cable)
751308-001 2.0-MP front-facing webcamera (includes cable and double-sided adhesive)
751309-001 5.0-MP rear-facing webcamera (includes cable)
751310-001 FPC cable (includes double-sided adhesive)
751312-001 Battery, 4100-mAh, Li-ion (includes cable and double-sided adhesive)
751313-001 Screw Kit
751314-001 Proximity/ambient light sensor board (includes cable and double-sided adhesive)
6 Chapter 3 Illustrated parts catalog
