HP StorageWorks MSA1000 Quickspecs

QuickSpecs
hp StorageWorks
modular SAN array 1000
specific for Tru64 UNIX and OpenVMS only
DA-11621 Canada — Version 2 — April 15, 2003 12
Configuration Information
STEP 4 – CHOOSE SUPPORTED OPTIONS FOR 2 GB OR 1 GB INFRASTRUCTURE (continued)
2 Gb Fibre Channel HBAs
FCA2354 Host Adapter (Tru64 UNIX, OpenVMS) 261329-B21
Fibre Channel Cables for 2 Gb
Infrastructure
Use 2 Gb Fibre Channel cables when connecting the msa Fibre Channel I/O Module or
the msa Fabric Switch 6 to FCA2101 HBA(s)
2 m LC-LC Multi-Mode Fibre Channel Cable
221692-B21
5 m LC-LC Multi-Mode Fibre Channel Cable
221692-B22
15 m LC-LC Multi-Mode Fibre Channel Cable
221692-B23
30 m LC-LC Multi-Mode Fibre Channel Cable
221692-B26
50 m LC-LC Multi-Mode Fibre Channel Cable
221692-B27
Fibre Channel Cables for 1 Gb
Fabric Switches and Hub
Use 1 Gb Fibre Channel cables when connecting the msa Fibre Channel I/O Module
and FCA2354 HBA(s) to 1 Gb fabric switches or hubs.
2 m LC-SC Multi-Mode Fibre Channel Cable
221691-B21
5 m LC-SC Multi-Mode Fibre Channel Cable
221691-B22
15 m LC-SC Multi-Mode Fibre Channel Cable
221691-B23
30 m LC-SC Multi-Mode Fibre Channel Cable
221691-B26
50 m LC-SC Multi-Mode Fibre Channel Cable
221691-B27
STEP 5 – CHOOSE HARD DRIVES & STORAGEWORKS ENCLOSURES
Hard Drives 36.4 GB Pluggable Ultra320 Universal Hard Drive, 10,000 rpm (1″) 286713-B22
72.8 GB Pluggable Ultra320 Universal Hard Drive, 10,000 rpm (1″) 286714-B22
146.8 GB Pluggable Ultra320 Universal Hard Drive, 10,000 rpm (1″) 286716-B22
18.2 GB Pluggable Ultra320 Universal Hard Drive, 15,000 rpm (1″) 286775-B22
36.4 GB Pluggable Ultra320 Universal Hard Drive, 15,000 rpm (1″) 286776-B22
72.8 GB Pluggable Ultra320 Universal Hard Drive, 15,000 rpm (1″) 286778-B22
*NOTE: All Ultra320 Universal Hard Drives are backward compatible to U2 or U3
speeds.
NOTE: For complete compatibility information, refer to the HP SCSI Hard Drive
Compatibility table located at: http://www.hp.com/.
NOTE: This Web site is available in English only.

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
