QuickSpecs
hp StorageWorks
modular SAN array 1000
specific for Tru64 UNIX and OpenVMS only
DA-11621 Canada — Version 2 — April 15, 2003 15
Technical Specifications
MODULAR SAN ARRAY 1000
LED Indicators on Front (3)
Power
Fault detected in one or more sub-systems
Fault in Enclosure Management
Drive Access (centre)
LED Indicators for Drive
Modules (3)
Online (left)
Drive Failure (right)
Power Supply/Blower Assembly Fault (1)
LED Indicators on Rear Panel
(4)
EMU (3) Power, A bus, B bus
Interface
Ultra3 SCSI to Hard Drives
2 Gb Fibre Channel to Hosts
Maximum Number of Drives
Fourteen, 1-inch HP Ultra2, Ultra3 or Ultra 320 Universal Hard Drives (msa1000 Cabinet); expandable to 42 using
two additional StorageWorks 4200/4300 Enclosures
Temperature Range
Operating
50° to 95°F/10° to 35°C
Shipping
–22° to 122°F/–30° to 50°C
NOTE: Derated 1°C per 1,000 feet of elevation to 10,000 ft.
Relative Humidity
Operating 10% to 90%
Non-operating Up to 95%
Input Power Requirements
Rated Input Voltage 100 to 240 VAC
Rated Input Frequency 50 to 60 Hz
Rated Input Current 6 A Max
Input Power (max) 549 W*
Heat Dissipation (max)
1876 Btu/hr*
* Input Power and Heat Dissipation specifications are maximum values and apply to worst-case conditions at full
rated power supply load. The power/heat dissipation for your installation will vary depending on the equipment
configuration.
msa1000 Cabinet
4U Rack Form Factor
Dimensions (H x W x D) 6.9 x 19 x 20.5 in/17.5 x 48.3 x 52.1 cm
Weight Net 55 to 85 lb/24.95 to 38.56 kg
Shipping Packaging
Dimensions (L x W x D) 28.5 x 14.81 x 33.13 in/72.4 x 37.6 x 84.1 cm
Weight Gross 75 to 105 lb/34.02 to 47.63 kg
