HP StorageWorks MSA1000 Quickspecs

QuickSpecs
hp StorageWorks
modular SAN array 1000
specific for Tru64 UNIX and OpenVMS only
DA-11621 Canada — Version 2 — April 15, 2003 14
Configuration Information
CONFIGURATION EXAMPLES
Two Node Redundant Cluster Solution
Quantity Description Part Number
1 HP StorageWorks Modular SAN Array 1000 201723-B22
1 msa1000 Controller 218231-B22
2
msa Hub 2/3 286763-B21
4 Host Adapter 261329-B21
4 2 m LC-LC Multi-Mode Fibre Channel Cable 221692-B21
14 36.4 GB Pluggable Ultra320 Universal Hard Drive, 15K 286776-B21
4 Host, 6TB, Redundant SAN Solution
Quantity Description Part Number
1 HP StorageWorks Modular SAN Array 1000 201723-B22
1 msa1000 Controller 218231-B22
2 256 MB Cache Modules for Controller (one additional for each controller) 254786-B21
2 msa SAN Switch 2/8 (Includes four 2Gb SFP transceivers) 288247-B21
8 Host Adapter (appropriate model for operating system)
8 2 m LC-LC Multi-Mode Fibre Channel Cable 221692-B21
2 StorageWorks Enclosure Model 4314R 190209-001
42
146.8 GB Pluggable Ultra320 Universal Hard Drive, 10,000 rpm (1″)
286716-B22

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
