HP StorageWorks P2000 G3 MSA System FC User Guide 67
NOTE: Connections to this device must be made with shielded cables with metallic RFI/EMI connector
hoods in order to maintain compliance with FCC Rules and Regulations.
Physical requirements
The floor space at the installation site must be strong enough to support the combined weight of the rack,
controller enclosures, expansion enclosures, and any additional equipment. The site also requires sufficient
space for installation, operation, and servicing the enclosures, and also requires sufficient ventilation to
allow a free flow of air to all enclosures.
Table 14 and Table 15 list enclosure dimensions and weights. Weights are based on an enclosure having
a full complement of disk drives, two controller or expansion modules, and two power supplies installed.
“2U12” denotes the LFF enclosure and “2U24” denotes the SFF enclosure.
.
.
1
Weights shown are nominal, and subject to variances.
2
Weights may vary due to different power supplies, IOMs, and differing calibrations between scales.
3
Weights may vary due to actual number and type of disk drives (SAS, SATA, SSD) installed.
Table 14 Rackmount enclosure dimensions
Specifications Rackmount
2U Height (y-axis) 3.45 inches (8.7 cm)
Width (x-axis):
• Chassis only
• Chassis with bezel ear caps
17.6 inches (44.7 cm)
18.9 inches (47.9 cm)
Depth (z-axis):
SFF drive enclosure (2U24)
• Back of chassis ear to controller latch
• Front of chassis ear to back of cable bend
LFF drive enclosure (2U12)
• Back of chassis ear to controller latch
• Front of chassis ear to back of cable bend
20.7 inches (52.6 cm)
23.6 inches (59.9 cm)
23.7 inches (60.2 cm)
26.4 inches (67.1 cm)
Table 15 Rackmount enclosure weights
Specifications Rackmount
P2000 G3 MSA SFF controller enclosure
• Chassis with FRUs (no disks)
1, 2
• Chassis with FRUs (including disk)
1,3
23.0 lb (10.4 kg) [chassis]
48.0lb (21.7 kg)
60.0 lb (27.2 kg)
P2000 G3 MSA LFF controller enclosure
• Chassis with FRUs (no disks)
1, 2
• Chassis with FRUs (including disks)
1,3
22.0 lb (9.9 kg) [chassis]
47.0 lb (21.3 kg)
68.0 lb (30.8 kg)
MSA2000 3.5" 12-drive enclosure
(12 di sks)
• Chassis with FRUs (no disks)
1, 2
• Chassis with FRUs (including disks)
1,3
22.0 lb (9.9 kg) [chassis]
47.0 lb (21.3 kg)
68.0 lb (30.8 kg)
P2000 6Gb 3.5” drive enclosure
(12 disks)
• Chassis with FRUs (no disks)
1, 2
• Chassis with FRUs (including disks)
1,3
22.0 lb (9.9 kg) [chassis]
47.0 lb (21.3 kg)
68.0 lb (30.8 kg)
