Set Host Mode operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of log information (0000000000 to 4294967295)
Detailed Information
Detailed information displays for this operation, as shown in Table 189.
Table 189 Set Host Mode Operation
DescriptionItem
The name of the port where the host group is created.Port
The host group number.HostGrpID
The host mode set. See the HP StorageWorks XP24000/XP20000 LUN Manager User's
Guide for the meaning of the host mode number.
Mode
The host mode option set. Hexadecimal values are output.
Option[0:31]
Option[32:63]
Option[64:95]
The number of host groups that the host mode setting is changed.
Num. of Host
Groups
Table 190 Values of Option and Host Mode Option
Host Mode OptionValue of Option
2 VERITAS Database Edition/Advanced Cluster0x20000000
6 TPRLO0x02000000
7 Automatic recognition function of LUN0x01000000
12 Undisplay function of ghost LUN0x00080000
13 SIM report at link failure0x00040000
NOTE:
When several options are set, a logical addition of their values is output. For example, 0x20080000 means
that 0x20000000: “2 VERITAS Database Edition/Advanced Cluster” and 0x00080000: “12 Undisplay
function of ghost LUN” are set.
Set Security Switch Operation
user-name,xx,YYYY/MM/DD,HH:MM:SS.xxx,00:00,[LUNM],Set Security Switch,,Normal end,Seq.=xxxxx
+{Port,Switch}=[{XX,Disable},{XX,Enable}],Num.of Ports=2
XP24000/XP20000 Audit Log User and Reference Guide 215
