DescriptionItem
The quorum disk ID that the ESAM pair uses. This value is output only when Change
ESAM is Yes.
Quorum Disk ID
The result of operation.
Normal end: Normal end, Error(xxxx-yyyyy): Abnormal end
xxxx: Part code, yyyyy: Error code
Result
The number of restored pairs.Num. of Pairs
Pairsplit-r Operation
user-name,xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,[Cnt Ac],Pairsplit-r,,Normal end,,,Seq.=xxxxxx
+{P-VOL(Port-G-ID-LUN),S-VOL(Port-G-ID-LUN),Type,S-VOL Write,Kind,Range,Mode,
Result}=
-{1A-0x00-0x000,1B-0x00-0x000,P-VOL,Disable,S-VOL,Group,Drain,Normal End},
{1A-0x00-0x001,1B-0x00–0x001,P-VOL,Disable,S-VOL,Group,Drain,Normal End},(snip)
-(snip), Num.of Pairs=xx
[Cnt Ac]
HP XP Continuous Access Software function
Pairsplit-r
Pairsplit-r operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of log information (0000000000 to 4294967295)
Detailed Information
Detailed information displays for this operation, as shown in Table 56.
Table 56 Pairsplit-r Operation
DescriptionItem
The port number, host group number, and LUN of the primary volume in the
split pair sequentially
P-VOL (Port-G-ID-LUN)
The port number, host group number , and LUN of the secondary volume in the
split pair sequentially
S-VOL (Port-G-ID-LUN)
The volume type of the volume on the primary site
P-VOL: Primary volume, S-VOL: Secondary volume
Type
Indicates whether writing to the secondary volume is enabled
Enable: Writing is enabled
Disable: Writing is disabled
S-VOL Write
XP24000/XP20000 Audit Log User and Reference Guide 99
