Item Component Spare part number
(1) Display assembly: The display assembly is spared at the subcomponent level only. For more display assembly spare part
information, see Display assembly subcomponents on page 12.
(2) Keyboard/top cover (includes keyboard cable): For a complete list of keyboard/top covers see Keyboard/top cover
on page 21.
(3) Power button board
NOTE: The power button board spare part kit does not include the power button board
cable. The power button board cable is available using spare part number 830757-001.
L02774-001
(4) Speakers (include left and right speakers and cables) L02775-001
(5) TouchPad board (includes double-sided adhesive)
NOTE: The TouchPad board spare part kit does not include the TouchPad board cable. The
TouchPad board cable is available using spare part number L02777-001.
L02788-001
(6) Battery (2-cell, 37 WH, 4.96 AH, Li-ion; includes cable) 824536-850
(7) Power connector 743480-004
(8) Audio board (includes audio jack and USB port)
NOTE: The audio board spare part kit does not include the audio board cable. The audio
board cable is available using spare part number 830759-001.
L02773-001
(9) WLAN module:
Intel Dual Band Wireless-AC 7265 802.11 AC 2×2 WiFi + Bluetooth 4.2 Combo Adapter 793840-005
(10) Heat sink (includes replacement thermal material) L02781-001
(11) System board (includes HDMI port, micro-SD card reader slot, USB port, WLAN slot, LVDS slot, DC in slot, and replacement
thermal material): For a complete list of system board descriptions see System board on page 30.
(12) Base enclosure L027801-001
Computer major components 11
