Reverse this procedure to install the WLAN module.
Heat sink
Description Spare part number
Heat sink (includes replacement thermal material) L02781-001
Before removing the heat sink, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 21).
5. Remove the battery (see Battery on page 26).
Remove the heat sink:
1. Remove the two Phillips PM2.0×2.2 broad head screws (1) that secure the heat sink to
the system board.
28 Chapter 5 Removal and replacement procedures
