Speakers
Table 5-7 Speakers description and part number
Description Spare part number
Speakers (includes cable) L61391-001
Before removing the speakers, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 23).
2. Remove the bottom cover (see Bottom cover on page 24).
3. Remove the battery (see Battery on page 25).
Remove the speakers:
1. Disconnect the speaker cable (1) from the system board.
2. Lift the speakers from the computer (2).
Reverse this procedure to install the speakers.
32 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
