b. Peel the antenna transceivers from the top of the display enclosure, and then remove the antennas
from the enclosure (2).
The antenna cables and transceivers are included in the WLAN Antenna Kit, spare part number
906173-001.
IMPORTANT: Be sure to note the way the antenna cable routes into the display hinge, as shown in
the following image.
Reverse this procedure to reassemble and install the display assembly.
Component replacement procedures 41
