Rear speakers
Component Spare part number
Rear speakers (include left and right rear speakers and cables) 786042-001
Before replacing the rear speakers, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the keyboard/top cover (see
Keyboard/top cover on page 19).
Remove the rear speakers:
1. Disconnect the rear speaker cable (1) from the system board.
2. Release the rear speaker cable from the retention clip (2) built into the base enclosure.
3. Remove the two Phillips PM1.9×2.8 screws (3) that secure the rear speakers to the base enclosure.
4. Remove the rear speakers (4) and cables.
Reverse this procedure to install the rear speakers.
Rear speakers 29
