Advanced Topics
42
Keyboard shortcuts
Table 4-5 lists the keyboard shortcuts for the StreamSmart Aplet. These shortcuts
are available either during or just after streaming.
Mathematical details: zoom, pan, and trace
Table 4-6 and Table 4-7 elaborate on how zooming and panning work. Table 4-
8 concludes the section with an explanation of tracing.
Table 4-5 Keyboard shortcuts
Key(s) Description
.
Toggles through the three options available for viewing a final data set after
streaming and prior to export. See Figure 4-31, Figure 4-32, and Figure 4-33.
Figure 4-31 Figure 4-32 Figure 4-33
/
Zooms in vertically, during or after streaming.
*
Zooms out vertically, during or after streaming.
+
Zooms in horizontally, during or after streaming.
-
Zooms out horizontally, during or after streaming.
ƒ$%+$$
Adds ten points to the currently selected data set, while in the Export menu.
ƒ$%-$$
Subtracts ten points from the currently selected data set, while in the Export
menu.
A
Opens the Sensor Setup menu.
B
Opens the Unit Setup menu.
E
After one or more vertical zooms, E returns to the original view of the
current data stream.
E @
After vertical, zooms on multiple streams, E @ returns all streams to their
original views.
