HP StreamSmart 400

Advanced Topics
44
Table 4-7 Pan
Table 4-8 Trace
Aplet
Feature
Key Description
Pan
W
Moves the stream itself upwards. The values of Ymax and
Ymin are decreased by equal amounts.
Pan
X
Moves the stream itself downwards. The values of Ymax and
Ymin are increased by equal amounts.
Pan
Y
Moves the stream itself to the right. The values of Xmin and
Xmax are decreased by equal amounts.
Pan
Z
Moves the stream to the left. The values of Xmin and Xmax are
increased by equal amounts.
Aplet
Feature
Key Description
Trace
Y
Moves the trace cursor along the data stream, from pixel to
pixel, to the right. The values of X-Min and X-Max only change
if the cursor traces beyond the right edge of the display.
Trace
Z
Moves the trace cursor along the data stream, from pixel to
pixel, to the left. The values of X-Min and X-Max only change
if the cursor traces beyond the left edge of the display.
