HP t5740e - Thin Client User Manual

To install the SO-DIMM:
1. Slide the serial number tab out of the way.
NOTE: Be sure not to lose this tab.
2. Remove the access plate:
Figure 2-10 Removing the SO-DIMM access plate
a. Remove the two screws securing the access plate to the chassis.
b. Lift the rear edge of the plate and pull the plate back and up off the chassis.
3. Hold the SO-DIMM at about a 20–degree angle and insert the SO-DIMM into the socket.
NOTE: A memory module can be installed in only one way. Match the notch on the module
with the tab on the memory socket.
Figure 2-11 Installing a SO-DIMM
4. Push the module into the socket, ensuring that the module is fully inserted and properly seated.
5. Press the module down into the compartment.
20 Chapter 2 Hardware Changes ENWW
