1. Overview
HP T750 G4 INTL UPS HP T1000 G4 INTL UPS
INPUT
OUTPUT
Refer to the Bottom of
the unit for caution markings!
RS232 OR
5
4
3
2
1
INPUT
OUTPUT
OUTPUT
Refer to the Bottom of
the unit for caution markings!
RS232 OR
5
4
3
2
1
HP T1500 G4 INTL UPS
INPUT
OUTPUT
Refer to the Bottom of
the unit for caution markings!
RS232 OR
5
4
3
2
1
(1) USB communication port
(2) RS-232 communication port
(3) Outlets for connection of critical equipment
(4) Socket for connection to AC power source
(5) Ground screw
