Introduction
This chapter provides component identification and serial number location for the
HP TFT5110R. Use the following information to locate and identify the components
of the TFT5110R.
Front Panel Components
1
2
3
4
Figure 1-1: Front panel components
Item Description
1 Power on/off switch
2 OSD scroll up button
3 OSD scroll down button
4 OSD activation button
