12 User Guide (Features may vary by model)
Computer Stand
The HP TouchSmart PC is shipped with the computer stand secured against the back of the computer. To
assure that the computer is in a stable position on your desktop, pull the computer stand open until it snaps
into place. Then, if you want to change the angle of the HP TouchSmart PC, hold each side of the
computer, and tilt it (the monitor moves forward; the stand stays in place) to an angle of between
5 degrees and 40 degrees from the vertical.
Computer Orientation
Your HP TouchSmart PC is designed to be operated in a landscape orientation (A). When wall-mounted,
the PC should remain with the display in landscape orientation, not portrait (B), or laid horizontal (C).
CAUTION: Make sure the angle of the computer is at least 5 degrees from the vertical;
otherwise the computer will be unstable and could fall over.
CAUTION: The computer stand stays in place as you increase the angle; the computer moves
forward. Take care that the computer screen does not move off the table.
5° min.
40°
max
CAUTION: Placing your PC in portrait orientation (B) or horizontal orientation (C) may result in
damage to the hardware components.
AB B C
