HP UPS R/T3000 User Manual

Component identification 11
Item Description
10 Cord retention clip attachment locations
11 Ground bonding screw
12 REPO port
13 Power cord with L6-20 plug
R/T3000 INT rear panel
Item Description
1 Option slot
2 USB port
3 Serial communications port
4 Load segment 1 (one IEC-320-C19 receptacle)
5 Load segment 2 (one IEC-320-C19 receptacle)
6 Load segment 1 (three IEC-320-C13 receptacles)
7 Load segment 2 (three IEC-320-C13 receptacles)
8 ERM connector
9 Cord retention clip attachment locations
10 Ground bonding screw
11 REPO port
12
Input power receptacle (IEC-320-C19) for country-specific plug
attachment
REPO port
The UPS includes an isolated REPO port. When properly wired, the REPO feature enables the power at
the UPS output receptacles to be switched off from a remote location. To use this feature, the REPO port

HP UPS R/T3000 Specifications

General

Power Capacity	3000 VA / 2700 W
Battery Type	Sealed Lead-Acid (SLA)
Rack Size	2U
Frequency	50/60 Hz
Operating Humidity	5% to 95% non-condensing
Form Factor	Rack/Tower
Output Voltage	230 VAC
Interface	USB, Serial
Output Connector(s)	IEC 320 C13, C19
Transfer Time	4 ms typical
Operating Temperature	0°C to 40°C
Battery Recharge Time	3 hours
