UPS front panel controls
Item Description Function
1 Test/Alarm Reset button
Silences UPS alarms ("Silencing an audible
alarm" on page 42)
2 Off button
Places the UPS in Standby mode (on page
38)
3 On button
Powers up the UPS ("Starting power to the
load" on page 26)
4 Battery Start button
Starts the UPS on battery power when
pressed with the On button
UPS front panel LED indicators
