HP V-M200 Safety And Regulatory Information

1-1
1
HP V-M200 802.11n Access Point
Specifications
HP V-M200 802.11n Access Point (J9467A NA, J9468A WW)
Electrical: For power, requires one of the following:
• External power adapter module*, or
• PoE PD connection to the Ethernet Port.
The access point is an IEEE 802.3af Compatible PD (PoE Powered Device) - Class 0.
* Use only the external power adapter module supplied with this product. Power adapter module
specification are provided below.
Universal power adapter module (5188-6700):
– AC Input Voltage: 100-240 V
– Maximum AC Input Current: 0.5 A
– AC Input Frequency Range: 50/60 Hz
– Power Consumption: 15 W
– DC Output Voltage: 12 ± 10% V
– Maximum DC Output Current: 1.25 A
Wall plug-in power adapter module (5184-5863,
5184-5864):
– AC Input Voltage: 100-240 V
– Maximum AC Input Current: 0.4 A
– AC Input Frequency Range: 50/60 Hz
– Power Consumption: 13 W
– DC Output Voltage: 12 ± 10% V
– Maximum DC Output Current: 1.085 A
Physical:
Dimensions: 195 mm (7.6 in) x 128 mm (5.0 in) x 32 mm (1.25 in)
Environmental:
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Relative humidity: 15% to 95% at 40°C (104°F), non-condensing
Non-Operating Temperature: -40°C to 70°C (-40°F to 158°F)
Non-Operating Relative
humidity: 15% to 95% at 65°C (149°F), non-condensing
Maximum Altitude: 4.6 km (15,000 ft)
Acoustic: Power: 0 dB (no fan)
Safety:
Stamdards: EN 60950-1:2006+A11:2009

HP V-M200 Specifications

General

Frequency Band	2.4 GHz
Antenna	Internal
Power over Ethernet (PoE)	No
Device Type	Wireless Access Point
Maximum Data Rate	300 Mbps
Wireless Standards	IEEE 802.11b/g
Security	WEP, WPA, WPA2
