82 Chapter4
Field Replaceable Units (FRUs)
Exchange and Nonexchange Part Numbers
The following Tables 4-2 lists the nonexchange part numbers for the J6000 workstation.
Table 4-2. J6000 Nonexchange Part Numbers
Numbers in Figure 4-1 Part Number Description
5 A5990-62023 CD ROM slim-line, ATAPI Assembly
6 A5990-66530 PCA, SCA backplane (disk drive)
7 A5990-62015 LCD/power switch assembly
8 0950-3812 VRM assembly
9 A5990-66520 PCA-PCI backplane board
Not Shown A1658-86004 Real Time Clock/Battery Module
10 A5990-62006 PCI cage assembly includes PCI tray fan
11 A5990-62003 Disk drive bracket assembly
Not Shown 1390-1266 Locking Thumbscrew
Not Shown 0515-2721 T15 Screw - M3x6 (Mounts CD ROM drive to
chassis, system board mounting, PCI backplane
mounting, and power supply mounting)
Not Shown 0380-2018 Jackscrew - 4 - 40Mx4F
Not Shown 0515-2332 M3 screws for mounting SCA board
12 A5990-62002
Main chassis assembly
1
14 A5990-63003 Internal SCSI cable
13 A5990-62004 Disk EMI cover assembly
Not Shown A5990-62005 Top cover assembly
14 A5990-62007 Front bezel assembly
Not Shown A5990-63004 CD ROM IDE cable
Not Shown A5990-40021 Trim - bezel bottom (with J6000 branding)
Not Shown A5990-40002 Trim - bezel bottom (blank - no branding)
Not Shown A5990-62002
J6000 Rack Mount Kit
2
Not Shown A5990-62020
Rack mounting hardware kit
2
Not Shown A5990-62021 Cable management assembly
Not Shown A5990-40006 Front bezel end caps
Not Shown A5990-40019
Right side cover (with logo)
3
Not Shown A5990-40020
Left side cover (with logo)
3
