HP Visualize j6000 - Removing the System Board

96 Chapter4
Field Replaceable Units (FRUs)
FRU Removal and Replacement
Removing the System Board
To remove the system board, do the following:
Figure 4-11. Removing the System Board
1
Remove VRM connectors and
VRM 0 and VRM 1 cards
2
- Remove screw from back of workstation to remove power plug
- Disconnect five connectors from system board (2-6)
4
2
3
6
1
5
Lift PCI handle to remove PCI cage from workstation
1
Remove memory cards from system board
1
2
VRM 0
VRM 1
2.
3.
1.
power plug
screw
power plug
