HP X34 User Manual

10
3. Illustrated parts catalog
To identify the monitor major components, use this illustration and table.
item
part name
q'ty
1
DECO
1
2
LENS
1
3
MIDDLE FRAME
1
4
MYLAR
1
5
POWER BOARD
1
6
KEY BOARD
1
7
LED BOARD
8
BASE
1
9
STAND
1
10
REAR COVER
1
11
MAINFRAME
1
12
SCALER BOARD
1
13
CONVERTER BOARD
1
14
PANEL
1
S1
SCREW M3
15
S2
SCREW M3
7
S3
SCREW M4
1
S4
SCREW M4
4

HP X34 Specifications

General

Screen Size	34 inches
Resolution	3440 x 1440
Panel Type	IPS
Aspect Ratio	21:9
Brightness	400 nits
Contrast Ratio	1000:1
Curvature	1500R
Adaptive Sync	AMD FreeSync Premium
Color Gamut	99% sRGB
VESA Mount	100 x 100 mm
HDR	HDR 400
Response Time	1 ms
Ports	1 x DisplayPort 1.4
