DescriptionItem
The channel adapters and ports on the local storage system. The following information appears
to the right of the icon:
Tree
Channel adapter (Fiber Channel interface)
Target port
RCU target port
Initiator port
External port
Port in initiator/external mix mode
The ports on the local storage system:Operation
• Port: Port number.
• Attribute: Port attribute (i.e., initiator, target, RCU target, external, or initiator/external)
• PCB Mode: Mode of the port. The mode is either Standard, High, or MIX.
• Error Code: An error code.
DKC Status dialog box
This dialog box lets you view status and other information about the logical path.
174 Continuous Access Journal Z GUI reference
