Document No. : Ludao disassembly SOP station :
Operation Name : Ver. : Edit date
Step：
Standard Operation Procedure
Notice: Please inform production line leader or master if you found any abnormal..
Fixture list (Spec.) Qty
Symbol
Safe
Order
Hear
Look
manu
al
Static
Qual
ity
Fix
tur
e
Issue Department：
Lister：
Zhou. Gui-lin
Industrial Engineering Class
Disassemble TBT/B
1. Take the screws*2（pic1）
the torque force of the driver is 1.5+/-
0.2kgf.cm
2. Take out the TBT vertically upward；
（pic2）
When taking out the TBT from the
middle frame， do not shake from left
to right to prevent the TBT BRK surface
from scraping off the patient.
8(1/2)
pic1
M2 screw
pic2
For TBT SKU
Half finger insert 1
#1 electric screw driver 1
2020/7/1
0.20
To Next Page
