HP Z220 CMT Series User Manual

HP Z420 Workstation rear panel
Figure 2-6 Rear panel components
Table 2-6 Component descriptions
1
Power supply Built-In Self Test
(BIST) LED
9
Audio line-out connector (green)
2 Universal chassis clamp opening 10
Microphone connector (pink)
3
PS/2 mouse connector (green) 11
AMT-enabled RJ-45 network
connector (orange)
4
USB 2.0 ports (4, black) 12 USB 3.0 ports (2, blue)
5 Security slot 13
IEEE-1394a FireWire connector
(white)
6 Padlock loop 14
PS/2 keyboard connector
(purple)
7
Audio line-in connector (blue) 15 Rear power button
8 Graphics card connector 16 Power cord connector
HP Z420 Workstation components
13

HP Z220 CMT Series Specifications

General

Chipset	Intel C216
Network	Integrated Intel 82579LM Gigabit Ethernet
Form Factor	Convertible Minitower (CMT)
Processor Options	Intel Core i3, Intel Core i5, Intel Core i7
Memory	Up to 32 GB DDR3
Storage Options	3.5" Hard Disk Drives
Graphics	Integrated Intel HD Graphics, NVIDIA Quadro, AMD FirePro
Expansion Slots	1 x PCIe x16, 1 x PCI
Ports	2 USB 3.0
Operating System	Windows 8 Pro, Windows 7 Professional
Power Supply	400W (90% efficiency)
Dimensions	17.5 inches
