HP Z22n - Mechanical Instructions; Remove Hinge Assembly; Remove Rear Cover

32
10. Mechanical Instructions
Step Figure Description
Remove the
HINGE ASS'Y
Press the button
to remove the
hinge assy
Remove the
REAR_COVER
Remove the
screws first.
Remove the
REAR_COVER
Use the tool to
remove the Rear
cover
