HP Z230 SFF Workstation

System Board
System Board Form Factor ATX 24.38 x 24.38 mm (9.6 x 9.6 inches)
Processor Socket Single LGA 1150
CPU Bus Speed DMI
Chipset Intel® PCH C226
Memory Expansion Slots 4 DDR3 memory slots
Memory Type Supported DDR3, UDIMM (Unbuffered), ECC& non-ECC
Memory Modes Non-Interleaved for single channel. Interleaved when both channels are populated.
Memory Speed Supported 1600MHz DDR3
Memory Protection ECC available on data
Maximum Memory 32GB
Memory Configuration
(Supported)
4GB and 8GB non-ECC/ 2GB, 4GB and 8GB ECC unbuffered DIMMs are supported.
ECC and non-ECC memory DIMMs cannot be mixed on the same system.
NOTE: * Maximum memory capacities assume 64-bit operating systems, such as Genuine Windows® 7
Professional 64-Bit or Red Hat Linux 64-bit. 32-bit Windows Operating Systems support up to 4 GB.
PCI Express Connectors 1 PCI Express Gen3 x16 LP slot (x16 electrical/x16 mechanical)
1 PCI Express Gen2 x16 LP slot (x4 electrical/x16 mechanical)
1 PCI Express Gen2 x1 LP slot (x1 electrical/x4 mechanical)
1 PCI Express Gen2 x1 LP slots (x1 electrical/x1 mechanical)
NOTE: LP = Low Profile
NOTE: In the PCIe Gen3 slot (x16 electrical/x16 mechanical) slot, if it is not being used for a graphics card,
only cards certified as After Market Options for this platform are supported.
Supported Drive
Interfaces
SATA Integrated (5) Serial ATA interfaces (6Gb/s SATA). One port can
optionally be used for eSATA.
RAID 0 and 1 supported. Factory integrated RAID is Microsoft
Windows only.
Serial Attached SCSI None
Integrated RAID NOTE: Requires identical hard drives (speeds, capacity,
interface)
Integrated Graphics Integrated Intel HD Graphics 4600 (on Core i5/i7-4xxx
processors); Integrated Intel HD Graphics P4600 (on Intel Xeon
E3-12x5v3 processors).
Based on Unified Memory Architecture (UMA)- A region of
system memory is reserved and dedicated to the graphics
display.
Support for Microsoft DirectX 11, OpenGL 4.0 and OpenCL 1.2
on Intel HD Graphics P4600;
3 DP 1.2 graphics ports integrated in motherboard; Supports up
to three simultaneous displays across DP outputs. Max.
resolution supported: 3840x2160 @60Hz
QuickSpecs
HP Z230 SFF Workstation
System Technical Specifications
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 15
