How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
POWER BD MA43HHC-BGBL-HU(C)
Z43
M74414-001
755.A2403.A001
Capacitors and connectors are available for purchase from the following EU distributors:
 Digi-Key (RUBYCON ALU CAP): www.digikey.com
Capacitors by distributor
Component
description
Location
Component
distributor
Distributor part number
CAP EL 680U 25V M P5
10X16 ZLH RUBYCON
AC561,AC562,AC563,
AC564,AC565,AC566,
AC567
RUBYCON
25ZLH680MEFCT810X16
https://www.digikey.de/product-
detail/en/rubycon/25ZLH680MEFCT810X16/118
9-4174-3-ND/3568140
Connectors by manufacturer
Component
description
Location
identifier
Component
distributor
Distributer part number
Remark
Phone Jack
PJ1
Adam Tech
https://www.digikey.com
PN:
2057-ASJ-192-Y-T/R-ND
Modify the rear cover I/O metal and plastic.
Modify the wire as below
HDMI
HDMI1
Switchcraft
Inc.
https://www.digikey.com
PN:
137-RAHHD19TR-ND
Mini DP
DP2
Pulse
Electronics
Network
https://www.digikey.com
PN:
E9320-001-01
Modify the rear cover I/O metal and plastic.
Modify the Pin to SMT type
DP
DP1
Molex
https://www.digikey.com
PN:
WM14328DKR-ND
1.Only DP1.1
2.Cut off the through hole
